Yamaha A-S1200 Integrated Amplifier

Yamaha A-S1200 Integrated Amplifier
  • Yamaha A-S1200 Integrated Amplifier
  • Part Number
    :
    A-S1200
  • Category
    :
    Integrated Amplifier
  • Lead Time
    :
    Ex Stock (free local delivery)
  • Price
    :
    HK$16,980.00/pc

  • Color *
    :
  • Qty
    :
  • Rating
    :
    0 reviews

Specifications :

A-S1200

Specifications

Maximum Power (4 ohms, 1kHz, 0.7% THD, for Europe)      160 W + 160 W

High Dynamic Power/Channel (8/6/4/2 ohms)      105/135/190/220 W

Damping Factor      ≧ 250 (1 kHz, 8 ohms)

Frequency Response       +0 / -3 dB (5Hz-100kHz) , +0 / -0.3 dB(20 Hz-20 kHz)

RIAA Equalization Deviation   +/-0.5 dB (PHONO (MM/MC))

Dimensions (W x H x D)  435×157×463 mm; 17-1/8" x 6-1/8" x 18-1/4"

Weight     22.0 kg; 48.5 lbs

Receiver / Integrated Amplifier

Rated Output Power       [20 Hz-20 kHz, 0.07% THD] 90 W + 90 W (8 ohms), 150 W + 150 W (4 ohms)

Total Harmonic Distortion (20Hz to 20kHz)    [Input 0.5 V] PHONO MC→LINE2 OUT: 0.02% (1.2 mVrms), PHONO→LINE2 OUT: 0.005% (1.2 Vrms), CD, etc.→SP OUT: 0.035% (50 W/8 ohms)

Signal-to-Noise Ratio      PHONO MC: 90 db, PHONO MM: 96 dB, CD, etc.: 110 dB

Input Sensitivity       [1 kHz, 100 W/8 ohms] PHONO MC: 150 uVrms/50 ohms, PHONO MM: 3.5 mVrms/47 kohms, CD, etc.: 200 mVrms/47 kohms, MAIN IN: 1 Vrms/47 kohms

Transformer    625VA (Toroidal)
